Range

During Economical Cruising at 10,000 ft, Reserve of 45 min
973 NM / 1,802 km
FL100, Maximum Power, Full Tank, Reserve of 45 min

832 NM / 1,540 km

Max. Cruising Speed

Maximum cruising power, 10,000 ft

195 kts / 361 km/h

Takeoff Distance

MTOW, Sea Level, ISA, No Obstacles

1,399 ft / 426 m

Landing Distance

No Reverse, Sea Level, ISA, No Obstacles, MLW

1,039 ft / 317 m

Engine

P&W
PT6A-140

Engine Power

867 shp

Number of Seats

Pilots + Passengers

1 + 9 or 2 + 9

Avionics

Garmin G1000 NXi
MAIN DIFFERENCES

Understand why the Grand Caravan EX is a grand airplane.

Interior executivo Interior carga

VERSATILITY

No matter what your mission, the Grand Caravan EX serves you perfectly. Its large cabin enables quick reconfiguration, adapting perfectly to any need, either for transporting cargo, luggage, or up to nine passengers (plus the crew). The aircraft can still operate on more than 99.8% of the registered runways in Brazil, thanks to its ability to land and take off on short (only 426 m) and adverse runways, such as in grassy fields or dirt.

PERFORMANCE

The Grand Caravan EX offers better climb performance and higher cruising speed than its predecessor, and is able to reach 185 kts (343 km/h), get up to 25 thousand feet of altitude, with a maximum range of up to 1,689 km (at 10,000 feet in economy cruise and 45 minutes of reserve), which allows you to fly from São Paulo to Cuiabá nonstop.

RUGGEDNESS

Robustez1
Robustez2 Great for operations on farm runways, the Caravan 675 perfectly serves typical agribusiness missions, which usually involve heavy loads and long distances.

AVIONICS

The Grand Caravan EX comes equipped with Garmin NXi avionics, recognized as one of the most reliable in the world.
Avionicos
DESIGN
Timeless but with significant developments over the years, the design of the Grand Caravan EX has become iconic for aviation lovers.
IMAGE GALLERY
INTERIOR SPACE
Big in comfort too, the Grand Caravan EX comfortably accommodates up to nine passengers (plus crew), or can be configured to carry luggage, cargo or even, in specific versions, parastatal agencies.
Seating configurations:
10 Commuter 13 Club 13 Commuter 14 Commuter A 14 Commuter B
*Outside of Brazil, the aircraft is available in other configurations with more seating. Consult local regulations.
DETAILED SPECIFICATIONS
DIMENSIONS
Length 12.67 m
Height 4.60 m
Wingspan 15.87 m
CABIN
Seats (pil. + pass.) 1 + 9 or 2 + 9
Length 5.10 m
Height 1.37 m
Width 1.63 m

WEIGHTS
Maximum Takeoff Weight 8,807 lb (3,995 kg)
Payload 1,602 kg
Maximum Fuel 335 gal (1,269 L)

LUGGAGE CAPACITY
Total Weight 639 kg
Total Volume 4.05 m3



PERFORMANCE
Maximum Range1 973 NM (1,802 km)
Max. Cruising Speed2 195 kts (361 km/h)

Takeoff
Takeoff Distance3 1,399 ft (426 m)

Landing
Landing Distance4 1,039 ft (317 m)
Service Ceiling 25,000 ft (7,620 m)
Rate of Climb 1,275 ft/min

EQUIPMENT
Engine P&W PT6A-140
Avionics Garmin G1000 NXi

1 During Economical Cruising at 10,000 ft, Reserve of 45 min
2 Maximum cruising power, 10,000 ft
3 MTOW, Sea Level, ISA, No Obstacles
4 No Reverse, Sea Level, ISA, No Obstacles, MLW
